The KJG-68 Hollow Paddle Dryer is an energy efficient, versatile industrial drying solution engineered specifically for pharmaceutical powders and API drying applications. With 68 m² heat transfer area, 5.21 m³ effective volume, and 45 kW drive, it delivers pharmaceutical-grade drying performance at industrial scale with maximum energy efficiency.
| Model | KJG-68 Hollow Paddle Dryer |
| Heat Transfer Area | 68 m² |
| Effective Volume | 5.21 m³ |
| Revolution | 10-20 r.p.m |
| Power | 45 kW |
| Width of Dryer Body (A) | 1,652 mm |
| Total Width (B) | 2,134 mm |
| Length of Dryer Body (C) | 5,842 mm |
| Total Length (D) | 9,296 mm |
| Distance Inlet to Discharge (E) | 5,384 mm |
| Height in Center (F) | 1,220 mm |
| Total Height (G) | 2,362 mm |
| Steam Inlet (N) | (2) 1-1/2" |
| Water Outlet (O) | (2) 1-1/2" |
The KJG-68 delivers energy efficient, versatile drying specifically for pharmaceutical powders and API drying. Typical applications include: Active Pharmaceutical Ingredient (API) wet cake drying, pharmaceutical intermediate powder processing, excipient and filler powder drying, wet granulation drying for tablet compression, pharmaceutical fine chemical powder processing, and high-potency API containment drying. The versatile design accommodates a wide range of pharmaceutical product specifications with rapid changeover capability.
The KJG-68 combines energy efficient operation with versatile processing capability for pharmaceutical-grade API drying at industrial scale. With 68 m² heat transfer area and pharmaceutical-compliant construction, it is the reliable high-capacity choice for pharmaceutical manufacturers requiring consistent quality, maximum efficiency, and GMP compliance.
